3-PHASE STEPPING DRIVER CF31022M

3-PHASE STEPPER DRIVER CF31022M

Overview
 CF31022M is in the industry of new based high-speed DSP+IPM full digital 3-phase stepper motor driver based on the increase of advance intelling control algorithm and the desigh of a new feneration of 3-phase high pressure stepping motor drive, the motor suitabity extemal signal suitability, receiving pulse frequency, service life, reliability and srability than ordinary DSP+IPM mode has greatly raised almost stepping motor, positioning a accuracy highest can amount to 60000 steps/turn

Key Features
1.High-low pressure double mode, suitable for low pressure 50V to 300V low voltage motor high voltage motor
2.Single pulse dual mode, suitable for pulse+direction mode and CW,CCW double pulse mode
3.Equipped with 16 file view of constant torque segmentation, the highest resolution 60000 steps/turn
4.The highest numerous response frequency can reach 500 Kpps, is the traditional drive receiving pulse frequency
5.Photoelectric is olation signal input/output
6.5V,12V,24V signal input compatible, need not external current limiting resistor
7.Drive current virtual value from 1.2 A/phase to 7.0A/phase point, 16 file adjustable
8.Single power input, voltage range: AC110V-230V

Please contact us for more details if need.
